Connector TM 24785

Poles
Voltage
Clock position
  • screw terminals
  • with highly heat resistant contact carrier
  • nickel plated contacts
  • with protective cap
  • (form DS)
  • Part no.24785
  • EAN4015394260837
  • Std. Pack. 10 Qty.

Technical specifications

Connector TM 24785

Ampere 32 A
Poles 5 p
Voltage 400 V
Clock position 6 h
Hertz 50-60 Hz
Connection technology Screw terminals
Contact highly heat resistant contact carrier
nickel plated contacts
Protection type IP 67
Weight 452 g
Declaration of Conformity CN,CQC
