Show all Cepex Design / Show all Wall mounted Cepex double receptacle
MENNEKES Wall mounted Cepex double receptacle 4203

Wall mounted Cepex double receptacle 4203

Ampere 16 A
  • screw terminals
  • further variants on request
  • Part no.4203
  • EAN4015394022541
  • Std. Pack. 5

Technical specifications

Wall mounted Cepex double receptacle 4203

Ampere 16 A
Poles 3 p
Voltage 230 V
Clock position 6 h
Hertz 50-60 Hz
Protection type IP44
Shutter No
Weight 462 g
Certifications CQC

Datasheets & Downloads

Wall mounted Cepex double receptacle 4203

Product infoWall mounted Cepex double receptacle 4203 PDF, 128 KB
CAD data STPWall mounted Cepex double receptacle 4203 ZIP, 417 KB
CAD data 3D DWGWall mounted Cepex double receptacle 4203 ZIP, 892 KB
Dimensional drawing portraitWall mounted Cepex double receptacle 4203 PNG, 81 KB
Dimensional drawing landscape formatWall mounted Cepex double receptacle 4203 PNG, 82 KB

Directives

Wall mounted Cepex double receptacle 4203

REACh
RoHS

Appropriate accessories

Wall mounted Cepex double receptacle 4203

MENNEKES Spacer frame 4191

Spacer frame

Part no. 4191

to compensate for unequal heights, matching all Cepex surface mounted receptacles (Data, SCHUKO®, 16 A and 32 A)

more
