MENNEKES Panel mounted receptacle 1278
MENNEKES Panel mounted receptacle 1278 images3d

Panel mounted receptacle 1278

Poles
Voltage
Clock position
  • screw terminals
  • for horizontal installation
  • 15° inclination
  • Part no.1278
  • EAN4015394009177
  • Std. Pack. 10
You can manage our products in various lists in the shopping list / shopping basket area.
Please give the new list a name
  • Please enter a list name
  • The list name already exists
  • Please enter a valid list name

Technical specifications

Panel mounted receptacle 1278

Ampere 16 A
Poles 3 p
Voltage 230 V
Clock position 6 h
Hertz 50-60 Hz
Connection technology Screw terminals
Contact standard
Protection type IP44
Flange 85x85 mm
Fixing hole 70x70 mm
Inclination 15 °
Weight 138 g
Certifications EAC

Directives

Panel mounted receptacle 1278
