What is a rotating field control test plug?

Three-phase sockets must be connected in such a way that there is a clockwise rotating field. The rotating field control test plug differs from normal plugs due to its transparent housing. By means of two control lamps inside the housing, this plug indicates whether the field is rotating in a clockwise or anticlockwise direction and checks that all 3 phases are present. This shows the direction of the rotating field. If the rotating field is correct, the green lamp lights up; if the rotating field is incorrect, the red lamp lights up and if a phase is missing, both lamps light up. More information

What do I use a phase inverter product for?

If a three-phase motor runs in the incorrect direction, our phase inverter products solve the problem quickly and safely. Use a screwdriver to release the lock and turn the insulating section with the two phase pins - the motor will now run in the opposite direction. More information

What does the colour of a product signify?

The colour of a product relates to the nominal operating voltage. Our plugs and connectors are available, for example in Red, Blue, Yellow, Green and Black. You can find an overview of the colour codes and what they relate to at: more information

Can I get a feedback signal from the CEE plug and socket?

Yes, for 63A and 125A receptacles and plugs and connectors, this can be done with a so-called pilot contact switch or a PCS (PilotContactSwitch). (Pay attention to the “P” index for the part number) Pilot contact: this involves another sleeve being added to the internal wiring, which uses the standard pin on the plug to establish a lagging connection. PCS: this involves a switch being installed in the internal wiring. It is a normally open contact with no potential, which is mechanically provided with a lagging current via the pin in the plug. In both cases this has to be requested when ordering; retrofitting is not possible. With some types of 16-amp and 32-amp receptacles it is possible to install an auxiliary switch: part no. 41000 (retrofitting possible). Relevant appropriate receptacles are listed in the MENNEKES catalogue.

Does MENNEKES offer solutions that can be secured with a padlock or lock cylinder?

Yes, MENNEKES has several solutions available: Stainless steel receptacle combinations, CombiTOWER®, bollards and Cepex receptacles are equipped with a lock cylinder and can therefore be locked. It is also possible to equip DUO-interlocked receptacles and windows on combination enclosures with a padlock.

How does this work if there is a price difference?

Please do not make any unauthorised deductions on your own. Please send your debit note to vi@MENNEKES.de Please state the reason and/or the basis for the debit (quotation number, old reference number, etc.), as well as your reference details (order number or invoice number)

Is there a stand available for the mobile EverGUM®?

Our EverGUM® combination units are suitable for free-standing floor applications. A stand is therefore not required.

Is there a data sheet for each receptacle combination? How do I go about getting one? Who do I ask?

Yes. A data sheet is available for download for each standard receptacle combination on the product detail page. For customer-specific solutions, a schematic diagram and an electric circuit diagram are included in the product text.

Are declarations of conformity available for products from MENNEKES, and, if so, how do I go about obtaining these?

For products of our product range, you can download the declarations of conformity from the respective product pages, or you can request them. If it is a new receptacle combination that was customised to the needs of the customer, a declaration of conformity will only be available after the order has been received and the first device has been produced.

Can you lock the main switch of DUO receptacles even in the activated state?

No, the deactivation function is a safety aspect.

Questions & answers

What are the initial symmetrical short-circuit current (IK) values of products from MENNEKES?

Our products have various IK values. Your contact at MENNEKES will be happy to tell you the IK value for the specific part number.

How can I find out what IP (ingress protection) rating I need?

Please refer to the IP (ingress protection) chart. More information

Are receptacle combinations from MENNEKES tested and approved by the VDE institute (or equivalent body)?

Receptacle combinations from MENNEKES can be subject to various product standards. Usually, we manufacture product series in accordance with IEC 61439, IEC 60309 and VDE 0620.

What is the difference between articles 1128A and 1128P?

Articles 1128A and 1128P (Panel mounted socket with screw contact) are almost identical products. However, article 1128P has a pilot contact that can be used for additional signalling/controlling.

What is the extra pin used for in 63-amp and 125-amp plugs?

The extra pin is called a pilot pin and it can be used to control additional signals (e.g. clearance of plug and socket/signal activation).

Are there schematic diagrams for 3KRAFT® and AirKRAFT® products?

Product information sheets with dimensional drawings of 3KRAFT® and AirKRAFT® products can be found on the corresponding product detail pages. There are no schematic diagrams for these product groups.

Are there IP5x EverGUM® products?

The standard IP protection classes for the EverGUM® product series are IP 44 and IP 67. Another protection class can be considered on a case-by-case basis.

What does the standard 60309 mean?

The standard DIN EN / IEC 60309 is an international standard for plugs and sockets, electric couplers and device connectors that are primarily intended for industrial use (with nominal operating voltages of up to 1000 V, 500 Hz and a nominal current of up to 125 A). Part 1 of the standard describes the general requirements for all industrial connectors. Part 2 specifies a series of connectors with round housings with different numbers and arrangements of contact pins for different applications. Our CEE plugs and sockets are manufactured in accordance with this standard.

What does the standard BS EN 61439 mean?

The standard DIN EN / IEC 61439 replaced the standard 60439 at the end of 2014. The standard describes the design and test specifications for low-voltage switchgear combinations. The standard defines the safety requirements for devices that are used to distribute electrical energy in industry, in private households and on construction sites. The standard guarantees a higher safety standard and is used, for example, for energy distributors, switchgear and distribution cabinets. More information

What do I use a 7-pin device for?

7-pin plugs and sockets can be used for any application that requires additional contacts.
