Wall mounted receptacle 7153

Ampere 63 A
Poles
Voltage
Clock position
  • screw terminals
  • X-CONTACT®
  • with DIN rail, optional fitting of Neozed, Diazed, circuit-breakers and RCD´s
  • Part no.7153
  • EAN4015394112242
  • Std. Pack. 1 Qty.

Technical specifications

Wall mounted receptacle 7153

Ampere 63 A
Poles 4 p
Voltage 400 V
Clock position 6 h
Hertz 50-60 Hz
Connection technology Screw terminals
Contact X-CONTACT®
Protection type IP 44
Enclosure material Plastic
Weight 2250 g
Declaration of Conformity CN,CQC
